Pléiades Neo full archive and tasking

How To Access Data

Project Proposal (Restrained)

  1. Go to the ESA User Services Portal
  2. Register or log in to EO Sign In
  3. After logging in, complete and submit the form with your proposed use of the data
  4. The proposal will be evaluated by ESA, which normally takes between 4 and 6 weeks
  5. Upon successful evaluation, you will receive a confirmation email, which describes the amount of data to be provided, and details of how to order the data.
Read More

The collection is open for research and application development, prototype and test projects to users located in the territory of ESA Member States (including Canada) and in the European Commission Member States.

Data are available to order on demand upon submission of a Project Proposal subject to evaluation and acceptance by ESA and the data owner.

 ESA will support as many high-quality and innovative projects as possible within the quota limit available, therefore only a limited amount of products can be allowed to each project.

The products are available as part of the Airbus provision from Pleiades and Spot missions. SPOT collection has worldwide coverage: the GeoStore Catalogue can be accessed (self registration requested) to discover and check the data readiness.

To complement the traditional and fully customised ordering and download of selected Pléiades and SPOT images in a variety of data formats, you can also subscribe to the OneAtlas Living Library where the entire OneAtlas optical archive is made available in streaming mode and updated on a daily basis.

Search (based on parameter or AOI) and View functionalities are accessible via the OneAtlas Living Library portal or via API The library offers three different subscription packages:

  • a limit of 80,000 tiles (corresponding to 8,000 km2)
  • a limit of 160,000 tiles (16,000 km2)
  • an all-you-can-eat (unlimited) access Subscriptions are active for one year.

All details about data provision and availability, data access conditions, usage restrictions and the quota assignment procedure are described in the Terms of Applicability document available in the Resources section.

If you need help with the proposal form, consult this guide on how to access data requiring a project proposal

For further information about the EO Sign In Service you can visit TellUs

Should you need support to prepare your proposal or access the data, please contact EOHelp

Description

Very High Resolution optical Pléiades Neo data at 30 cm PAN resolution (1.2 m 6- bands Multispectral) are available as part of the Airbus provision with twice daily revisit capability over the entire globe. The swath width is 14 km (footprint at nadir).

Band combinations:

  • Panchromatic one band Black & White image at 0.3 m resolution
  • Pansharpened colour image at 0.3 m resolution: Natural colour (3 bands RGB), false colour (3 bands NIRRG), 4 bands (RGB+NIR), 6 bands
  • Multispectral colour image in 4 bands (RGB+NIR) or 6 bands (also Deep blue and Red Edge) at 1.2 m resolution
  • Bundle 0.3 m panchromatic image and 1.2 m multispectral image (4 or 6 bands) simultaneously acquired

Geometric processing levels:

  • Primary: The Primary product is the processing level closest to the natural image acquired by the sensor. This product restores perfect collection conditions: the sensor is placed in rectilinear geometry, and the image is clear of all radiometric distortion.
  • Projected: The products is mapped onto the Earth cartographic system using a standard reference datum and projection system at a constant terrestrial altitude, relative to the reference ellipsoid.
  • Ortho: The Ortho product is a georeferenced image in Earth geometry, corrected from acquisition and terrain off-nadir effects.



All details about the data provision, data access conditions and quota assignment procedure are described in the Terms of Applicability available in Resources section.

Details

DATA SET SPECIFICATIONS

Spatial coverage:
90 N, -90 S, -180 W, 180 E
Temporal coverage:
2021-04-28 - present - present
Date of launch:
28/04/2021, 16/08/2021
Operators:
Airbus
Mission status:
Ongoing
Orbit height:
620 km
Orbit type:
Sun-synchronous
Swath width:
14 km at nadir
Resolution:
Very High Resolution - VHR (0 - 5m)
Wavelengths:
VIS (0.40 - 0.75 µm), NIR (0.75 - 1.30 µm)

PROCESSING LEVEL

Level 1A (Primary), Level 2A (Projected), Level 3 (Ortho)

APPLICABLE TERMS & CONDITIONS

Specific restrictions to the use of data may apply for TPMs according to the terms of applicability valid for each mission. Utilisation of this data is subject to ESA's Earth Observation Terms and Conditions.
READ T&C

RESOURCES

Website

Airbus Constellation portal

Website

Visit page
Catalogue

OneAtlas Portal

Catalogue

Visit page
Data Access Information

OneAtlas Guide

Data Access Information

Visit page
Data Access Information

One Tasking Guide

Data Access Information

Download
Access Guide

SPOT, Pleiades and Pléiades Neo Terms of Applicability

Access Guide

Visit page
Data Access Information

Guidelines for the submission of Project Proposal

Data Access Information

Visit page
